WTS: Power DLS Ultimate A7 (Surabaya)
Dijual power DLS Ultimate A Series A7 (5Channel)
4x60W dan 1x300W
kekurangan Tutup power belakang hilang jadi pakai papan
Jual 6,75jt saja
Surabaya
Minat hub 081 2324 9559
Number of channels 5
Amplifier class AB
Mono bridge mode 4 ohm 2 x 200 W RMS
Output power in 2 ohm 4 x 100 W RMS
Output power in 4 ohm 4 x 60 W RMS
Mono sub channel output in 1 ohm 600 W RMS
Mono sub channel 2 ohm 440 W RMS
Mono sub channel 4 ohm 300 W RMS
Frequency range 10 Hz - 50 kHz
Damping factor > 200
S/N ratio, A-weighted > 100 dB
Low level output No
Input impedance, high level N/A
High level input with auto start No
Input sensitivity 0,3 - 7 V
Input impedance > 10 kohm
Filters channel A & B HP: 80 - 400 Hz / 1,6 - 8 kHz (x20)
Filters channel C & D HP: 80 - 400 Hz. LP: 0,3 - 4 kHz / 3 - 40 kHz (x10)
Filter sub channel LP: 50 - 125 Hz
Phase control for subwoofers 0-180 degrees cont. variable
External cooling fan terminal Yes
Remote bass level control Yes
Remote phase shift control Yes
Power consumption (idle) 1,1A
Power consumption (max) 120 A
Rec. power cable Minimum 4AWG / 21 mm2
Fuses 2 x 35 A + 2 x 20 A
Dimension (W x D x H) 605 x 240 x 73 mm (23,82 x 9,45 x 2,87 inches)
Weight 8,1 kg ( 17,86 lb)
|
