High end 2-way AVI LXD-130 5.25 inch midbass driver + HF-30B + passive x-over......



SOLD









HF-30B Tweeter







HF-30B, 30 mm (1.2") Dome Tweeter



This tweeter is the king of all Tweets! It is currently the largest car audio tweeter available. The neodymium magnet is 3 times the size as the one used in the HF-25T. It produces the highest output of power among all of the tweeters. The mounting hole is 50 mm, so the increased performance you get is only by a 5 mm difference. This tweeter is for very high performance 2, 3 or 4 way sound systems. The suggested operating range is 2.5 to 20 KHz., and the minimum crossover frequency is 2.3 KHz.













AVI LXD-130, 130 mm (5.25") MIDBASS DEVICE





This is a midbass device for very high performance sound systems.

Suggested operating range is 110 Hz to 8.5 KHz.











The LXD-130 comes neck to neck in popularity compared with the MXD-130. Over the years, it has gone through many redesigns and changes to achieve near perfection now. The LXD-160 were probably one of the first midbass devices which used a massive 30 oz magnet . It is designed for very high performance sound systems, and the operating range is suggested at 110 Hz to 8.5 KHz.







PERFORMANCE



90 Hz to 12 KHz at -10 dB points, without crossover.

150 Hz to 8 KHz at -3 dB points, without crossover.

150 watts music program material.

100 watts AES pink noise rating.

92 dB average, at 1 watt and 1 meter, in half space.

4 ohm nominal, 3.0 ohm minimum.





FEATURES



Black aluminum frame with cavity vents.

Extended and vented pole piece with integrated bottom plate.

Both top and bottom plates with CNC and black absorbing finish.

Black PP Mica cone with composite rubber edge.

636 g (22.4 oz) magnet.

50 mm (2") aluminum ribbon voice coil.

PHYSICAL 134 X 134 mm (5.3" X 5.3") overall size.

70 mm (2.76") overall depth without grille.

120.5 mm (4.7") cut out hole diameter.

65 mm (2.6") mounting depth without grille.

63 mm (2.5") mounting depth with grille.

1.74 Kg (3.8 lbs) weight.

T/S DATA

Znom 4 Ohms Revc 3.0 Ohms Fo 66.9 Hz

Sd 0.0087 M2 (13.5 in.squared) Le 0.392 mH SPL 92 dB

Xmax 3.25 mm (0.13 in) Qms 5.335 BL 6.36 TM

Vas 7.74 L (0.27 cu.ft.) Qes 0.238 Pnom 100 W

Cms 736.8 �m/N Qts 0.228 Pmax 150 W
